产品参数 外壳尺寸：匹配16B外壳 | ||
插芯 | ||
接插件针数 | Number Of Contacts | 24,42,72,108+PE |
额定电流 | Rated Current | 10A |
额定电压 | Rated Voltage | 250V |
额定脉冲电压 | Rated Impulse Voltage | 4KV |
污染程度 | Pollution Degree | 3 |
材料 | Material | 聚碳酸酯 |
工作温度范围 | Limiting Temperatures | -40℃~125℃ |
UL94阻燃等级 | Flammability Acc. To UL94 | V0 |
可拔插次数 | MecHEnical Working Life-mating Cycles | ≥500 |
插针 | ||
材料 | Material | 铜合金 |
表面处理 | Surface | 镀金/镀银 |
接触电阻 | Contact Resistance | ≤3mΩ |
接线形式 | 螺钉连接 | |
导线规格 | Wire Gauge | 0.14-2.5mm² |
AWG | AWG | 26-14 |
绝缘电阻（Ω） | Insulation Resistance | ≥1010 |
